HPC and Big Data Technologies for Global Challenges
EU founded project@OITTTIO
personal story: EC cares (2020)
… to have a reproducible benchmarking, optimisations, and visualisations.
… to provide how to reproduce the experiments in line with open science and open data standards.
… scientifically rigorous reporting results
Popper convention
- verbal instructions are NOT safe and/or "rigorous"
- instead, provide a set of precise configs and scripts that describe
- available packages and default preferences
- how to deploy the software
- how to produce plots
- must report metadata
If you do not make a performance study, it's as simple as this:
take/create a list of required packages
numpy==1.18.2
scipy>=1.1.0
pandas
mpi4py
profilehooks
and run pip
pip install -r requirements.txt
report/store the existing software environment
pip freeze > requirements.txt
It's like a little bit harder.Like a little...
... except a lot?
Spack at the 1st place?rpm / apt / yum or Homebrew / conan are insufficient?rpm, yum, apt, yast, etc.)
Homebrew, etc.)
Common disadvantage:
PyPI or poetry:
conda:
Spack:
PyPI: incredible amount of packages that are not yet in Spackconda: Windows supportSpack
Syntax of spec (sigils, etc)
$ spack install python # unconstrained
$ spack install python@3 # @ custom version
$ spack install python@3.9%clang # % custom compiler
$ spack install python@3.9%gcc@5.4 +optimizations~debug # +/- build option
$ spack install python@3.9 cppflags="-O3 –g3" # set compiler flags
$ spack install python@3.9 target=skylake # set target microarchitecture
$ spack install python@3.9 ^openssl@1.1:%clang ^readline@8 # ^ dependency information
installed packages can be referred by hash
$ spack find -l readline
==> 2 installed packages
-- linux-ubuntu16.04-broadwell / gcc@5.4.0 ----------------------
sei2v7j readline@8.0 feqfow6 readline@8.0
$ spack install python@3.9 ^openssl@1.1:%clang ^/feq # / hash
concretize or find -l)package name
$ spack list # all packages
$ spack list *pyth* # simple filters
$ spack list -d MPI # also search the description for a match (apt-chache search)
list extensible packages
$ spack extensions # extendable packages
==> Extendable packages:
aspell go-bootstrap jdk lua mofem-cephas openjdk python ruby spiral yorick
go icedtea kim-api matlab octave perl r rust tcl
list Python extensions
$ spack extensions -s packages python | head -n4
==> python@3.9.0%gcc@5.4.0+bz2+ctypes+dbm~debug+libxml2+lzma~nis+optimizations+pic...
==> 1345 extensions:
adios2
akantu
version
$ spack versions python # basic
$ spack versions *mpi* # include virtual packages in list
$ spack list --format version_json *mpi* # print output JSON with versions, deps, homepage, path to package
compiler
$ spack compilers # list of specs for registered compilers
$ spack compiler list # ----/----
$ spack compiler info clang # know better about configs of specific compilers
cppflags, cflags, cxxflags, and fflagsldflags, and ldlibsvariants and dependencies
$ spack info libosrm
CMakePackage: libosrm
Description:
libOSRM is a high performance routing library written in C++14 designed
to run on OpenStreetMap data.
Homepage: http://project-osrm.org/
Tags:
None
Preferred version:
5.24.0 https://github.com/Project-OSRM/osrm-backend/archive/v5.24.0.tar.gz
Safe versions:
5.24.0 https://github.com/Project-OSRM/osrm-backend/archive/v5.24.0.tar.gz
Variants:
Name [Default] Allowed values Description
==================== ============== =====================================
build_type [Release] Debug, Release The build type to build
doxygen [off] on, off Install with libosmium
ipo [off] on, off CMake interprocedural optimization
lib_only [on] on, off Install OSRM in a library only mode
osmium [off] on, off Install with libosmium
protozero [off] on, off Install with third party Protozero
shared [off] on, off Enables the build of shared libraries
Installation Phases:
cmake build install
Build Dependencies:
binutils boost bzip2 cmake doxygen git intel-tbb libosmium libxml2 libzip
lua pkg-config protozero zlib
Link Dependencies:
boost bzip2 doxygen intel-tbb libosmium libxml2 libzip lua protozero zlib
Run Dependencies:
None
Virtual Packages:
None
list virtual packages
$ spack providers
Virtual packages:
D fftw-api golang lapack mysql-client rpc unwind
awk flame iconv mariadb-client opencl scalapack yacc
blas gl ipp mkl osmesa sycl
daal glu java mpe pil szip
elf glx jpeg mpi pkgconfig tbb
get providers list
$ spack providers mpi
mpi:
fujitsu-mpi mpich@1: mpt@3: mvapich2x openmpi@2.0.0:
intel-mpi mpich@3: mvapich2 nvhpc spectrum-mpi
intel-oneapi-mpi mpilander mvapich2@2.1: openmpi
intel-parallel-studio mpt mvapich2@2.3: openmpi@1.6.5
mpich mpt@1: mvapich2-gdr openmpi@1.7.5:
full specification of the current platform
$ spack arch -f # frontend
$ spack arch -b # backend
parts of specification of the current platform
$ spack arch -b -t # only the target
$ spack arch -b -p # only platform
$ spack arch -b -o # only the operating system
list platforms defined in Spack
$ spack arch --known-targets #
from spack import *
class Libosrm(CMakePackage):
"""libOSRM is a high performance routing library written in C++14
designed to run on OpenStreetMap data."""
homepage = "http://project-osrm.org/"
url = "https://github.com/Project-OSRM/osrm-backend/archive/v5.24.0.tar.gz"
maintainers = ['sgo-go']
# To add checksums for more versions, one can use =spack checksum libosrm=
version('master', branch='master')
version('5.24.0', sha256='a66b20e7ffe83e5e5fe12324980320e12a6ec2b05f2befd157de5c60c665613c')
version('5.23.0-rc.2', sha256='bc1f6024bbfd491bddaf02ac9a15fc7786274e22fd1097014a4590430fd41199')
version('5.23.0-rc.1', sha256='df4ad08a758be487809f477fbbdc80558c5bca3ed2a24b8719fb636a6ace8b36')
version('5.23.0', sha256='8527ce7d799123a9e9e99551936821cc0025baae6f2120dbf2fbc6332c709915')
version('5.22.0-customsnapping.3', sha256='414922ec383f9cbfcb10f2ced80688359f1ee5e87b920b0d00b3d6eda9b5925b')
version('5.21.0-customsnapping.11', sha256='9dcb8795ae8c581264655c818dfc2f33f394557869a738675cc41021e1c07b78')
version('5.21.0-customsnapping.10', sha256='bbd6c3878ec559742f700e92202a7239a6c61cedfc399921f68b7d4e5eb30eb4')
version('5.21.0-customsnapping.9', sha256='933b6bb7b29b0f96d54814ac5d81478e0de1a05cb3f1e3d6748c941c3efc87bd')
version('5.21.0-customsnapping.8', sha256='ff1ac87b8671145a6dbf8d2985df07627293c939794f49b9114574f48821f2ca')
version('5.21.0-customsnapping.7', sha256='34562aa5ee13dd18113d926ab91147ca29677ceddec21e8e11676c51c51012a2')
variant('shared', default=False,
description='Enables the build of shared libraries')
variant('build_type', default='Release',
description='The build type to build',
values=('Debug', 'Release'))
variant('osmium', default=False,
description='Install with libosmium')
variant('doxygen', default=False,
description='Install with libosmium')
variant('protozero', default=False,
description='Install with third party Protozero (otherwise download it during installation)')
# ---- See about OSRM library at:
# https://github.com/Project-OSRM/osrm-backend/blob/master/docs/libosrm.md
variant('lib_only', default=True,
description='Install OSRM in a library only mode')
# Build-time dependencies:
# depends_on('m4', type='build') # build-essential
depends_on('binutils', type='build')
depends_on('pkg-config', type='build')
depends_on('cmake@3.1:', type='build', when='@5.21:')
depends_on('git', type='build', when='@master')
# depends_on('expat@2.2.6:')
depends_on('bzip2')
depends_on('libxml2')
depends_on('libzip')
depends_on('zlib')
depends_on('boost@1.54.0:')
depends_on('lua@5.2:')
depends_on('intel-tbb') # 2019.3
depends_on('libosmium', when='+osmium')
depends_on('doxygen', when='+doxygen')
depends_on('protozero', when='+protozero')
conflicts('%gcc', when='@:5.0', msg='libOSRM needs C++14 support (GCC >= 5)')
# conflicts('+cxx', when='@:0.6', msg='Variant cxx requires Julia >= 1.0.0')
# conflicts('@:0.7.0', when='target=aarch64:')
# conflicts('@:0.5.1', when='%gcc@8:', msg='Julia <= 0.5.1 needs GCC <= 7')
def setup_build_environment(self, env):
env.set('LC_CTYPE', 'en_US.UTF-8')
env.set('LC_ALL', 'en_US.UTF-8')
env.set('BOOST_INCLUDEDIR', self.spec['boost'].headers.directories[0])
env.set('BOOST_LIBRARYDIR', self.spec['boost'].libs.directories[0])
def cmake_args(self):
variant_bool = lambda feature: str(feature in self.spec)
cmake_args = []
cmake_args.append('-DLUA_INCLUDE_DIR=%s' % self.spec['lua'].headers.directories[0])
cmake_args.append('-DBUILD_SHARED_LIBS:BOOL=%s' % variant_bool('+shared'))
cmake_args.append('-DBoost_USE_STATIC_LIBS=ON') # %s' % variant_bool('+shared')
return cmake_args
Supported build systems:
Spack: Command install$ spack install python@3.9+optimized # install the package along with all its dependencies
$ spack install -f requirements.yml # install from file (similar to pip -r)
$ spack install --only package python@3.9 # install only the package or only the dependencies
$ spack install --only dependencies python@3.9 # install only the package or only the dependencies
$ spack install -j32 python@3.9+optimized # explicitly set 32 parallel jobs
$ spack install --fail-fast python@3.9 # stop all builds if any build fails
$ spack install -y python@3.9+optimized # use "yes" to every confirmation request
$ spack install --overwrite python@3.9 # reinstall an existing spec
Spack: Mirrors, Tests, and LoggingMirrors
$ spack install -n libosrm # do not use checksums to verify downloaded files (unsafe)
$ spack install --no-cache libosrm # do not check for pre-built Spack packages in mirrors (by default =--use-cache=)
$ spack install --cache-only libosrm # only install package from binary mirrors
$ spack install --no-check-signature libosrm # do not check signatures of binary packages
Tests
$ spack install --test root libosrm # run package tests for top-level packages
$ spack install --test all libosrm # run package tests during installation for all packages
Logs (CDash\(^*\) and junit reporters)
$ spack install --log-format cdash libosrm # use CDash format to be used for log files
$ spack install --log-file osrm.log libosrm # filename for the log file. if not passed a default will be used
$ spack install --help-cdash # show usage instructions for CDash reporting
Spack: Debugging options# Debug
$ spack install -v libosrm # display verbose build output while installing
$ spack install --show-log-on-error libosrm # print full build log to stderr if build fails
$ spack install --keep-prefix libosrm # don't remove the install prefix if installation fails
$ spack install --dont-restage libosrm # if a partial install is detected, don't delete prior state
$ spack install --source libosrm # install source files in prefix
$ spack install --fake libosrm # fake install
$ spack install --dirty libosrm # preserve user environment in spack's build environment (danger!)
Spack: Installation steps. What can fail?Installation steps
Spack: What can fail? Concretizer$ spack spec -l boost libosrm # show dependency hashes as well as versions
$ spack spec -L boost libosrm # show full dependency hashes as well as versions
$ spack spec -I boost libosrm # show install status of packages.
$ spack spec -N boost libosrm # show fully qualified package names
$ spack spec -t boost libosrm # show dependency types
$ spack --color always spec -lIt libosrm | less -R
Input spec
--------------------------------
- [ ] .libosrm
Concretized
--------------------------------
[+] cljend3 [ ] hidalgo.libosrm@5.24.0%gcc@5.4.0~doxygen~ipo+lib_only~osmium~protozero~shared build_type=Release arch=linux-ubuntu16.04-broadwell
- faipele [b ] ^builtin.binutils@2.35.1%gcc@5.4.0+gold~headers~interwork~ld~libiberty~lto+nls~plugins arch=linux-ubuntu16.04-broadwell
- 5lobbsd [b ] ^builtin.diffutils@3.3%gcc@5.4.0 arch=linux-ubuntu16.04-broadwell
- cerl5gx [bl ] ^builtin.gettext@0.21%gcc@5.4.0+bzip2+curses+git~libunistring+libxml2+tar+xz arch=linux-ubuntu16.04-broadwell
[+] 44w5m3q [bl ] ^builtin.bzip2@1.0.6%gcc@5.4.0+shared arch=linux-ubuntu16.04-broadwell
[+] 2lu3ocr [bl ] ^builtin.libiconv@1.16%gcc@5.4.0 arch=linux-ubuntu16.04-broadwell
[+] qxsf3og [bl ] ^builtin.libxml2@2.9.10%gcc@5.4.0~python arch=linux-ubuntu16.04-broadwell
[+] uqlvynn [b ] ^builtin.pkg-config@0.29.1%gcc@5.4.0+internal_glib patches=49ffcd644e190dc5efcb2fab491177811ea746c1a526f75d77118c2706574358 arch=linux-ubuntu16.04-broadwell
[+] z4e64mz [blr ] ^builtin.xz@5.1.0alpha%gcc@5.4.0~pic arch=linux-ubuntu16.04-broadwell
[+] lhfrrg2 [bl ] ^builtin.zlib@1.2.11%gcc@5.4.0+optimize+pic+shared arch=linux-ubuntu16.04-broadwell
[+] kmjncy3 [bl ] ^builtin.ncurses@6.2%gcc@5.4.0~symlinks+termlib arch=linux-ubuntu16.04-broadwell
[+] j3btfe7 [bl ] ^builtin.tar@1.28%gcc@5.4.0 patches=08921fcbd732050c74ddf1de7d8ad95ffdbc09f8b4342456fa2f6a0dd02a957c,125cd6142fac2cc339e9aebfe79e40f90766022b8e8401532b1729e84fc148c2,5c314db58d005043bf407abaf25eb9823b9032a22fd12a0b142d4bf548130fa4,d428578be7fb99b831eb61e53b8d88a859afe08b479a21238180899707d79ce4 arch=linux-ubuntu16.04-broadwell
[+] teztdxn [bl ] ^builtin.boost@1.74.0%gcc@5.4.0+atomic+chrono~clanglibcpp~container~context~coroutine+date_time~debug+exception~fiber+filesystem+graph~icu+iostreams+locale+log+math~mpi+multithreaded~numpy~pic+program_options~python+random+regex+serialization+shared+signals~singlethreaded+system~taggedlayout+test+thread+timer~versionedlayout+wave cxxstd=98 visibility=hidden arch=linux-ubuntu16.04-broadwell
- begrqoj [b ] ^builtin.cmake@3.5.1%gcc@5.4.0~doc+ncurses+openssl+ownlibs~qt arch=linux-ubuntu16.04-broadwell
[+] oytuwse [bl ] ^builtin.intel-tbb@2020.3%gcc@5.4.0+shared+tm cxxstd=default patches=62ba015ebd1819c45bef47411540b789b493e31ca668c4ff4cb2afcbc306b476,ce1fb16fb932ce86a82ca87cf0431d1a8c83652af9f552b264213b2ff2945d73 arch=linux-ubuntu16.04-broadwell
[+] 3ctx5ya [bl ] ^builtin.libzip@1.2.0%gcc@5.4.0 arch=linux-ubuntu16.04-broadwell
[+] gaavhbi [bl ] ^builtin.lua@5.3.5%gcc@5.4.0+shared arch=linux-ubuntu16.04-broadwell
[+] sei2v7j [bl ] ^builtin.readline@8.0%gcc@5.4.0 arch=linux-ubuntu16.04-broadwell
[+] svmtcfx [ r ] ^builtin.unzip@6.0%gcc@5.4.0 arch=linux-ubuntu16.04-broadwell
-I shows by [+] packages installed with Spack
Spack: What can fail? ConcretizerSolutions:
-c / --cover (how extensively to traverse the DAG)
try clingo concretizer (e.g., see the issue #19951)
$ spack install clingo%aocc+python ^python@2.7.5
$ spack load clingo
$ python -m pip install --user --upgrade clingo
$ spack find -p clingo
package.pySpack: What can fail? DependencyFailed dependency can be identified with
$ spack install --fail-fast --only dependencies python@3.9
Solution:
Spack: What can fail? Config/Build/Install of PackageSolution:
install dependencies, stage package and switch there
$ spack clean python@3.9 # clean old builds
$ spack stage python@3.9 # stage package (in particular, create build directory)
$ spack cd python@3.9 # switch to build directory
… in the build environment
$ spack build-env python@3.9 bash # use build environment in bash session
package.py correspondingly
Spack: Reproducibility mechanismscontent of folder
ls -a $(spack location -i boost)
. .. include lib .spack
metadata (.spack)
$ tree $(spack location -i boost)/.spack
~/spack/opt/spack/linux-ubuntu16.04-broadwell/gcc-5.4.0/boost-1.74.0-teztdxn6e7aqxjlnactwivwoyrza5uan/.spack
├── install_manifest.json # info about files
├── repos # packages from repos required to install package
│ └── builtin
│ ├── packages
│ │ ├── boost
│ │ │ ├── 1.72_boost_process.patch
│ │ │ ├── boost_11856.patch
│ │ │ ├── boost_154.patch
│ │ │ ├── boost_1.63.0_pgi_17.4_workaround.patch
│ │ │ ├── boost_1.63.0_pgi.patch
│ │ │ ├── boost_1.67.0_pgi.patch
│ │ │ ├── bootstrap-path.patch
│ │ │ ├── call_once_variadic.patch
│ │ │ ├── clang-linux_add_option2.patch
│ │ │ ├── clang-linux_add_option.patch
│ │ │ ├── darwin_clang_version.patch
│ │ │ ├── fujitsu_version_analysis.patch
│ │ │ ├── nvhpc.patch
│ │ │ ├── package.py
│ │ │ ├── python_jam.patch
│ │ │ ├── python_jam_pre156.patch
│ │ │ ├── system-non-virtual-dtor-include.patch
│ │ │ ├── system-non-virtual-dtor-test.patch
│ │ │ └── xl_1_62_0_le.patch
│ │ └── zlib
│ │ ├── package.py
│ │ └── w_patch.patch
│ └── repo.yaml
├── spack-build-env.txt # build environment
├── spack-build-out.txt # output pdoduced during build
└── spec.yaml # fully concretized specs
We met already
$ spack list pyt* # basic search
$ spack list -d MPI # --search-description (also search the description)
$ spack list -v mpi # --virtuals (also include virtual packages like ~mpi~)
$ spack install python@3.9%clang+optimizations ^openssl@1.1
$ spack spec python@3.9%clang@3.8+optimizations~debug ^openssl@1.1
find: check what can be used?Mental model:
module avail
spec quiries
$ spack find ^python@3.7: # every installed package that depends on mpich
$ spack find cppflags="-O3" # built with cppflags="-O3"
many options
$ spack find -vdfpl libosrm # variants; dependencies; compiler flags; path; dependency hashes and versions
==> 1 installed package
-- linux-ubuntu16.04-broadwell / gcc@5.4.0 ----------------------
cljend3 libosrm@5.24.0%gcc ~doxygen~ipo+lib_only~osmium~protozero~shared build_type=Release \
~/spack/opt/spack/linux-ubuntu16.04-broadwell/gcc-5.4.0/libosrm-5.24.0-cljend3d5xl67apn443bisynsc2qow5n
...
oytuwse intel-tbb@2020.3%gcc +shared+tm cxxstd=default \
patches=62ba015ebd1819c45bef47411540b789b493e31ca668c4ff4cb2afcbc306b476,\
ce1fb16fb932ce86a82ca87cf0431d1a8c83652af9f552b264213b2ff2945d73\
~/spack/opt/spack/linux-ubuntu16.04-broadwell/gcc-5.4.0/intel-tbb-2020.3-oytuwsekyhdkpzgr23lpaikphlbi5b7i
...
extensions: check what can be used? Extensible packagesMental model:
pip freeze
same can be used to look for Python extensions
$ spack extensions -s installed -l python@3.9
==> 91 installed:
-- linux-ubuntu16.04-broadwell / gcc@5.4.0 ----------------------
jfsg4va py-absl-py@0.7.1 uvfpwty py-ipywidgets@7.5.1 wk45srk py-notebook@6.1.4
zaheb77 py-argon2-cffi@20.1.0 vb3fqto py-jedi@0.13.3 ia52w5s py-numexpr@2.7.0
6t6bpnu py-astunparse@1.6.3 qyep3ry py-jinja2@2.10.3 kl356sd py-numpy@1.19.4
hx3smrj py-async-generator@1.10 btz2obt py-joblib@0.14.0 vu2hbdd py-pandas@1.1.4
sm57agu py-attrs@20.3.0 zeezzki py-jsonschema@3.2.0 64thtja py-pandocfilters@1.4.2
hlkiwaw py-babel@2.7.0 ky5z5w3 py-jupyter@1.0.0 lx7tvvc py-parso@0.6.1
qrtn4qe py-backcall@0.1.0 fuwgb36 py-jupyter-client@6.1.7 lym624m py-pexpect@4.7.0
pfqlasj py-bleach@3.1.0 mivk4ck py-jupyter-console@6.1.0 nm2pvbb py-pickleshare@0.7.5
dqtwtaq py-bottleneck@1.2.1 otvcfqc py-jupyter-core@4.6.3 yhh6l3o py-pillow@8.0.0
xxfvwb3 py-cached-property@1.5.2 touqak7 py-jupyterlab-pygments@0.1.1 yggtq4k py-pip@20.2
cm4lc2e py-certifi@2020.6.20 cbigt3n py-keras@2.2.4 opm6xwx py-pkgconfig@1.5.1
dh6ieic py-cffi@1.14.3 f3eeils py-keras-applications@1.0.8 bmm2pm6 py-prometheus-client@0.7.1
loavcnk py-cycler@0.10.0 dq2lhng py-keras-preprocessing@1.1.2 5b22yba py-prompt-toolkit@2.0.9
lljlmpx py-cython@0.29.21 uyfbpmu py-kiwisolver@1.1.0 tm2do3c py-protobuf@3.12.2
qlttezg py-decorator@4.4.2 ecjsden py-markupsafe@1.1.1 6ltbrs4 py-ptyprocess@0.6.0
zet4w5e py-defusedxml@0.6.0 qvpjxp4 py-matplotlib@3.3.3 atkpmfo py-py@1.8.0
4krwyqj py-entrypoints@0.3 o2euz3e py-mistune@0.8.4 uxe5b4t py-pybind11@2.5.0
6jpojou py-gast@0.3.3 6blhip6 py-mpi4py@3.0.3 fypwsnl py-pycparser@2.20
ue4m7zr py-google-pasta@0.1.8 f7zo6x4 py-nbclient@0.5.0 lfpzpfz py-pygments@2.6.1
oqbyjff py-grpcio@1.32.0 fdqc7ms py-nbconvert@6.0.1 vqnjzqp py-pyparsing@2.4.2
mknyf7g py-ipykernel@5.3.4 srd52cl py-nbformat@5.0.7 l55llo6 py-pyrsistent@0.15.7
57ncgy7 py-ipython@7.18.1 vwhb77l py-nest-asyncio@1.4.0 pt74pv5 py-python-dateutil@2.8.0
3etfubk py-ipython-genutils@0.2.0 sra7n3k py-nose@1.3.7 4wrfs5r py-pytz@2020.1
load and activate: How to access packages?Mental model:
module load
load package
$ spack load --first libosrm@5.24.0 # first match if multiple packages match the spec
$ spack load --sh libosrm@5.24.0 # print sh commands to load the package
$ spack unload libosrm@5.24.0
$ spack unload -a # unload all loaded Spack packages
global activation/deactivation of extensions
$ spack activate py-numpy
$ spack activate -f py-numpy # without first activating dependencies
$ spack deactivate py-numpy
$ spack deactivate --all python
spack load openblas for py-numpy)load and activate: How to access packages? Check active packages
can check packages with find
$ spack load libosrm@5.24.0
$ spack find --loaded
==> 13 installed packages
-- linux-ubuntu16.04-broadwell / gcc@5.4.0 ----------------------
boost@1.74.0 intel-tbb@2020.3 libosrm@5.24.0 libzip@1.2.0 ncurses@6.2 unzip@6.0 zlib@1.2.11
bzip2@1.0.6 libiconv@1.16 libxml2@2.9.10 lua@5.3.5 readline@8.0 xz@5.1.0alpha
load package only
$ spack load --only=package libosrm@5.24.0
can check extensions with extensions
$ spack extensions -s activated -l python@3
uninstall$ spack uninstall python@3.9 #
$ spack uninstall -f python@3.9 # remove regardless of whether other packages or environments depend on this one
$ spack uninstall -R python@3.9 # also uninstall any packages that depend on the ones given via command line
$ spack uninstall -y python@3.9 # assume "yes" is the answer to every confirmation request
$ spack uninstall -a python@3.9 # remove all installed packages that match each supplied spec
Mental model: Python virtual environments with PyPI
Typical work flow for installing environment
$ spack env create sna
$ spack env activate sna
# Add specs to the environment
$ spack add python@3.9.0+optimizations
$ spack add py-numpy ^python@3+optimizations
$ spack add py-scipy ^python@3+optimizations
$ spack add py-scikit-learn ^python@3+optimizations
$ spack concretize
$ spack install
despacktivate
content of the folder
$ tree -a $(spack location -e sna)
~/spack/var/spack/environments/sna
├── .spack-env
│ └── transaction_lock
├── spack.lock
└── spack.yaml
content of spack.yaml
# This is a Spack Environment file.
#
# It describes a set of packages to be installed, along with
# configuration settings.
spack:
# add package specs to the `specs` list
specs: [python@3.9.0+optimizations, py-numpy ^python@3+optimizations, py-scipy ^python@3+optimizations,
py-scikit-learn ^python@3+optimizations]
view: true
open environment config in editor
$ spack config edit
1st iteration of improvements: matrices
spack:
specs:
- python@3.9.0+optimizations
- matrix:
- [py-numpy, py-scipy, py-scikit-learn]
- [^python@3.9.0+optimizations]
view: true
2nd iteration of improvements: definitions
spack:
definitions:
- packages:
- py-numpy
- py-scipy
- py-scikit-learn
- pythons: [python@3.9.0+optimizations]
# - compilers: [gcc@8.1.0]
specs:
- $pythons
- matrix:
- [$packages]
- [$^pythons]
# - [$%compilers]
view: true
3rd iteration of improvements: containers and concretization together
spack:
definitions:
- packages:
- py-numpy
- py-scipy
- py-scikit-learn
- pythons: [python@3.9.0+optimizations]
specs:
- $pythons
- matrix:
- [$packages]
- [$^pythons]
concretization: together
view: true
container:
format: singularity
spack:
packages:
python:
version: [3.9.0, "3.8:"]
variants: +optimizations
# buildable: true
specs:
- python
- matrix:
- [py-numpy, py-scipy, py-scikit-learn]
- [^python]
view: true
logical: a set of abstract specs (manifest)
$ spack env create sna spack.yaml
exact: a set of all fully concretized specs
$ spack env create sna spack.lock
concretize
$ spack concretize -f
Allow to define "a set of packages we want to install across a wide range of compilers".
matrix: cartesian product for lists of spec partsexclude: excludes specific combinations from matrixwhen: arch.satisfies('x86_64:'))opencl-headers, fastmathXsdkPythonPackage bundles: py-exodus-bundler, py-jupyterclass Fastmath(BundlePackage):
homepage = "https://fastmath-scidac.org/"
version('latest')
depends_on('amrex') # default is 3 dimensions
depends_on('chombo@3.2')
depends_on('hypre~internal-superlu')
depends_on('mpi')
depends_on('arpack-ng')
depends_on('petsc')
depends_on('phasta')
depends_on('pumi')
depends_on('sundials')
depends_on('superlu-dist')
depends_on('trilinos')
depends_on('zoltan')
Ceed)Spackcommon (lower-precedence scopes first):
| Scope | Locationn | Description |
|---|---|---|
defaults |
$SPACK_ROOT/etc/spack/defaults |
"factory" settings |
system |
/etc/spack |
settings for this machine |
site |
$SPACK_ROOT/etc/spack |
settings for Spack instance |
user |
~/.spack |
all instances of Spack for user |
| custom | options --config-scope or -C </path/to/scope> |
custom location |
<base-scope>/<platform>) (darwin, linux,…)$ spack config list
compilers mirrors repos packages modules config upstreams
| Section | Description |
|---|---|
| config | basic configuration options |
| packages | build customization |
| compilers | compiler definitions |
| mirrors | list of local and remote mirrors |
| repos | list of repos with build instructions |
| upstreams | installation trees of external Spack instances |
| modules | set up for mudulefile generation |
browsing and editing
$ spack config get upstreams
EDITOR=emacsclient spack config edit packages &
check end result for the superposition of scopes
$ spack config blame config
$ spack --insecure -C /path/to/first/scope -C /path/to/second/scope config blame config
update to the latest format (for the given Spack version)
$ spack config update config
$ spack config revert config
config:
# Directories
install_tree: # path to the root of the Spack install tree.
root: $spack/opt/spack
build_stage:: # temporary locations Spack can try to use for builds.
- $spack/var/spack/stage
test_stage: $spack/tmp/$user/test # directory to run tests and store test results.
source_cache: $spack/var/spack/cache # cache directory for tarballs and archived repositories.
misc_cache: $spack/var/$user/cache # cache directory for miscellaneous files.
# Options
install_missing_compilers: false # Spack will not build unavailable compiler in specs.
checksum: true # always check checksums after downloading archives.
ccache: false # do not use ccache to cache C compiles.
build_jobs: 32 # the maximum number of jobs in `make`
permissions
all:
permissions:
read: world # read-world is default, can remove
write: group
group: spack
uap_simulator:
permissions:
read: group
group: hid_uap
concretization preferences (for packages and virtual packages)
packages:
python:
compiler: [gcc@10.2.0]
variants: +optimization
version: [3.6, 3.9.0, 3.7]
all:
compiler: [gcc@10.2.0, 'clang@10:', 'gcc', intel]
target: [zen2]
providers:
mpi: [mpe, openmpi]
specification of external packages
mpt:
buildable: False
externals:
- spec: mpt@2.23
modules:
- mpt/2.23
openmpi:
externals:
- spec: openmpi@4.0.5
modules: [openmpi/4.0.5]
- spec: openmpi@4.0.4%gcc@9.2.0 arch=linux-centos8-zen2
prefix: /opt/hlrs/non-spack/mpi/openmpi/4.0.4-gcc-9.2.0
better to make MPI non-buildable for everything
mpi:
buildable: False
$ spack external find --not-buildable cmake
limited to finding a subset of common build-only dependencies (discoverable packages)
$ spack external list
==> Detectable packages per repository
Repository: builtin
python jdk gcc gpgme meson openssl
autoconf cpio gdal hugo mpich perl
automake cuda ruby intel mvapich2 pkg-config
bash diffutils ghostscript krb5 nag pkgconf
bazel findutils git libtool ncurses spectrum-mpi
bison fish git-lfs llvm ninja tar
bzip2 fj gmake lustre opengl texinfo
ccache flex gmt m4 openjdk xz
cmake fzf go maven openmpi
Spack does not
definition of compiler
- compiler:
spec: clang@10.0.0
paths:
cc: /opt/hlrs/non-spack/compiler/aocc/2.2.0/bin/aocc-clang
cxx: /opt/hlrs/non-spack/compiler/aocc/2.2.0/bin/aocc-clang++
f77: /opt/hlrs/non-spack/compiler/aocc/2.2.0/bin/aocc-flang
fc: /opt/hlrs/non-spack/compiler/aocc/2.2.0/bin/aocc-flang
flags: {}
operating_system: centos8
target: x86_64
modules: [aocc/2.2.0]
environment: {}
extra_rpaths: []
example of mixing (C/C++ from clang@8.0.0 with gfortran)
- compiler:
spec: clang-gfortran@3.8.0
paths:
cc: /usr/bin/clang-3.8
cxx: /usr/bin/clang++-3.8
f77: /usr/bin/gfortran
fc: /usr/bin/gfortran
operating_system: ubuntu16.04
flags:
cflags: -O3 -fPIC
target: x86_64
modules: []
environment: {}
extra_rpaths: []
automatic
$ module load gcc
$ spack compiler find gcc
by default it goes to ~/.spack/<os>/compilers.yaml
$ spack -C $SPACK_ROOT/etc/spack compiler find gcc
use Spack-installed compilers
$ spack install clang@8.0.0
$ spack -C $SPACK_ROOT/etc/spack compiler add $(spack location -i clang@8.0.0)
mirrors.yaml from default scope
mirrors:
spack-public: https://spack-llnl-mirror.s3-us-west-2.amazonaws.com/
specification of off-line mirror
mirrors::
hidalgo: file:///path/to/hidalgo/mirror
repos.yaml from default scope
repos:
- $spack/var/spack/repos/builtin
commands
$ spack create /path/to/new/repo hidalgo # create a new
$ spack list # show registered
$ spack add /path/to/repo # add to Spack's configuration
$ spack -C defaults rm builtin # remove from Spack's configuration
default location of Spack installations at Hawk
ll /opt/hlrs/spack/current
# lrwxrwxrwx 1 hpcoft28 hpc43203 18 Jul 3 2020 /opt/hlrs/spack/current -> rev-004_2020-06-17
more installations
ll /opt/hlrs/spack/rev*
# rev-008_2020-10-03
register it as an upstream
upstreams:
spack-hawk-new:
install_tree:
/opt/hlrs/spack/rev-008_2020-10-03
spack-hawk-default:
install_tree:
/opt/hlrs/spack/current
check packages compiled for the given microarchitecture
$ spack find target=zen2
| Local | Remote | Dependencies |
|---|---|---|
| AS | S | Python 2.6+ or 3.5+ |
| A | Extra modules of Python | |
| A | bash |
|
| A | ssh |
|
| S | A C/C++ compiler for building | |
| AS | make |
|
| A | S | tar, gzip, unzip, bzip2, xz |
| S | patch |
|
| S | git and curl for fetching |
inventory folder structure
inventory
├── 01-clusters.yaml
└── group_vars
├── HLRS.yaml
└── PSNC.yaml
hosts and groups definition (01-clusters.yaml)
---
HLRS:
hosts:
hawk:
ansible_host: hawk.hww.hlrs.de
vulcan:
ansible_host: vulcan.hww.hlrs.de
vars:
use_workspace: true
PSNC:
hosts:
eagle:
ansible_host: eagle.man.poznan.pl
hidalgo:
children:
HLRS:
PSNC:
vars:
spack_prefix: ~/spack-hidalgo/{{ inventory_hostname }}
use_workspace: false
check what variables Ansible set up in inventory for each host
ansible-inventory all -i inventory --graph --var
@all:
|--@hidalgo:
| |--@HLRS:
| | |--hawk
| | | |--{ansible_host = hawk.hww.hlrs.de}
| | | |--{ansible_user = hpcgogol}
| | | |--{spack_prefix = ~/spack-hidalgo/{{ inventory_hostname }}}
| | | |--{use_workspace = True}
| | |--vulcan
| | | |--{ansible_host = vulcan.hww.hlrs.de}
| | | |--{ansible_user = hpcgogol}
| | | |--{spack_prefix = ~/spack-hidalgo/{{ inventory_hostname }}}
| | | |--{use_workspace = True}
| | |--{ansible_user = hpcgogol}
| | |--{use_workspace = True}
| |--@PSNC:
| | |--eagle
| | | |--{ansible_host = eagle.man.poznan.pl}
| | | |--{ansible_user = gogolenko}
| | | |--{spack_prefix = ~/spack-hidalgo/{{ inventory_hostname }}}
| | | |--{use_workspace = False}
| | |--{ansible_user = gogolenko}
| |--{spack_prefix = ~/spack-hidalgo/{{ inventory_hostname }}}
| |--{use_workspace = False}
|--@ungrouped:
check accessibility of HiDALGO HPC infrastructure
ansible hidalgo -i inventory -m ping
PLAY [Ansible Ad-Hoc] **********************************************************
TASK [ping] ********************************************************************
ok: [vulcan]
ok: [hawk]
ok: [eagle]
PLAY RECAP *********************************************************************
eagle : ok=1 changed=0 unreachable=0 failed=0 skipped=0
hawk : ok=1 changed=0 unreachable=0 failed=0 skipped=0
vulcan : ok=1 changed=0 unreachable=0 failed=0 skipped=0
simple playbook: download locally and distribute
---
- name: Install Spack on HiDALGO infrastructure
hosts: hidalgo
gather_facts: no
vars:
spack_tarball: ./spack-0.16.1.tar.gz
spack_version: '0.16.1'
spack_checksum: 'md5:b6f9fdea5b5228f0a591c7cdcf44513c'
spack_extra_repos:
- $spack/var/spack/repos/hidalgo
tasks:
- name: Download new Spack release locally
run_once: True
delegate_to: localhost
delegate_facts: True
ansible.builtin.get_url:
url: 'https://github.com/spack/spack/releases/download/v{{ spack_version }}/spack-{{ spack_version }}.tar.gz'
dest: '{{ spack_tarball | default(".") }}'
checksum: '{{ spack_checksum }}'
force: no
register: spack_local_tarball
- name: Unarchive Spack tarball {{ spack_local_tarball.dest }} locally
unarchive:
src: '{{ spack_local_tarball.dest }}'
dest: '{{ spack_prefix }}'
extra_opts: [--strip-components=1]
creates: '{{ spack_prefix }}/bin/spack'
launch
ansible-playbook -i inventory -l hawk,eagle install_spack.yml
task for creating configs from variables
- name: Mock =repos.yaml= to enable accessing additional repos
ansible.builtin.copy:
content: |
repos:
{{ spack_extra_repos | default([]) | to_nice_yaml }}
dest: '{{ spack_prefix }}/etc/spack/repos.yaml'
force: true
result
ssh hawk 'cat ~/spack-hidalgo/hawk/etc/spack/repos.yaml'
repos:
- $spack/var/spack/repos/hidalgo
Not really...
What about "off-line" clusters?!mirror
mirror for individual specs
- name: Mirror individual packages
ansible.builtin.shell:
cmd: |
spack \
mirror create -D -n{{ spack_mirror_versions_per_spec }} -d {{ spack_mirror_dir }} \
{{ spack_mirror_packages | join(' ') }}
creates: '{{ spack_mirror_dir }}'
when: spack_mirror_packages is defined and (spack_mirror_packages | length > 0)
~/.spack
Spack will ignore packages defined in packages.yaml (non-buildable)~/.spackspack graph -d libosrm | dot -Tpdf | zathura -
spack graph -d libosrm | dot -Tsvg -o/tmp/spack.stdin.svg && eog /tmp/spack.stdin.svg
spack graph -i -d | dot -Tsvg -o./full_installation.svg # all installed (not only in env)
mirror for individual specs
- name: Mirror individual packages
ansible.builtin.shell:
cmd: |
spack -C {{ tempdir_spack_build.path }}/etc/spack \
mirror create -D -n{{ spack_mirror_versions_per_spec }} -d {{ spack_mirror_dir }} \
{{ spack_mirror_packages | join(' ') }}
creates: '{{ spack_mirror_dir }}'
environment:
PATH: "{{ ansible_env.PATH }}:{{ tempdir_spack_build.path }}/bin"
when: spack_mirror_packages is defined and (spack_mirror_packages | length > 0)
tempting solution: put the following text to packages.yaml
packages:: {}
packages.yaml from etc/spack/defaults to '{{ tempdir_spack_build.path }}/etc/spack'- name: Mirror environments
ansible.builtin.shell:
cmd: |
. {{ tempdir_spack_build.path }}/share/spack/setup-env.sh && \
spack env create --without-view tmpenv{{ index }} {{ item }} \
&& spack env activate tmpenv{{ index }} \
&& spack -C {{ tempdir_spack_build.path }}/etc/spack concretize \
&& spack -C {{ tempdir_spack_build.path }}/etc/spack \
mirror create -a -n{{ spack_mirror_versions_per_spec }} -d {{ spack_mirror_dir }}
# environment:
# PATH: "{{ ansible_env.PATH }}:{{ tempdir_spack_build.path }}/bin"
loop: "{{ spack_mirror_envs | flatten(levels=1) }}"
loop_control:
index_var: index
when: spack_mirror_envs is defined
If Ansible inventory is available,
take exact or prepare logical Spack environment. E.g.,
spack:
specs:
- python@3.9.0+optimizations
- matrix:
- [py-numpy, py-scipy, py-scikit-learn]
- [^python@3.9.0+optimizations]
view: true
run Spack deployment playbook
ansible-playbook -i inventory install_spack.yml
launch Spack command for installing environment
ansible hidalgo -i inventory -m shell -a \
'cmd=". {{ spack_prefix }}/share/spack/setup-env.sh \
&& spactivate sna && spack install"'
Highlights
Spack config variables from deployment rules in AnsibleResult
Ansible
platform (hardware, OS): variable '{{ ansible_facts }}'
- name: Collect facts returned by facter
ansible.builtin.setup:
gather_subset:
- '!all'
- '!min'
- hardware
filter: "*processor*"
"exact" software: slurp spack.lock and report it with
{{ spack_env_lock['content'] | b64decode | from_json | to_nice_yaml }}
Ansible: Alternative for reporing soft
"exact" software: options --yaml and --json
spack find --json
spack spec -y libosrm
spec:
- libosrm:
version: 5.24.0
arch:
platform: linux
platform_os: ubuntu16.04
target:
name: broadwell
vendor: GenuineIntel
features:
- adx
- aes
- avx
- avx2
- bmi1
- bmi2
- f16c
- fma
- mmx
- movbe
- pclmulqdq
- popcnt
- rdrand
- rdseed
- sse
- sse2
- sse4_1
- sse4_2
- ssse3
generation: 0
parents:
- haswell
compiler:
name: gcc
version: 5.4.0
namespace: hidalgo
parameters:
build_type: Release
doxygen: false
ipo: false
lib_only: true
osmium: false
Ansible: From compute noderun from Eagle compute node
ansible all -i 127.0.0.1, -m ansible.builtin.setup --connection=local
known issues
facts:
discovered_interpreter_python: /usr/bin/python
processor:
- '0'
- GenuineIntel
- Common KVM processor
- '1'
- GenuineIntel
- Common KVM processor
- '2'
- GenuineIntel
- Common KVM processor
- '3'
- GenuineIntel
- Common KVM processor
- '4'
- GenuineIntel
- Common KVM processor
- '5'
- GenuineIntel
- Common KVM processor
- '6'
- GenuineIntel
- Common KVM processor
- '7'
- GenuineIntel
- Common KVM processor
- '8'
- GenuineIntel
- Common KVM processor
- '9'
- GenuineIntel
- Common KVM processor
- '10'
- GenuineIntel
- Common KVM processor
- '11'
- GenuineIntel
- Common KVM processor
processor_cores: 12
processor_count: 1
processor_nproc: 12
processor_threads_per_core: 1
processor_vcpus: 12
/proc/cpuinfoSpack
Singularity and Docker containersCDash support and GitLabCI pipelinesSpack tutorial by Todd GamblinSpack by Gregory Blum Beckeroshch (Oleksandr) and ktokm (Kamil)
